Name:2-PC Forged Steel Floating Ball Valve
Category: Floating Ball valve
Online services:
Print this Page
|
Add to Favorites
|
Skype Online
|
Email
|
 PDF DownLoad
|
|
| << Prev Products Next Products >> | |
| Details | Send Inquiry |
|---|
| General Description: SIGNI forged steel floating ball valves featuring 2-pc or 3-pc forged steel split body side entry design. Specially designed for high pressure service in order to replace traditional trunnion mounted design to save cost. Upon special request, this series of valve can also designed to have Cryogenic or High temperature service. | |
Design Standard: | |
Basic Design: BS 5351, API 608, EN 1983 (DIN 3357) Face to Face (End to End): ASME B16.10, EN 558 End Connection: ASME B16.5, ASME B16.25, EN 1092 Test: API 598, EN 12266, BS 6755, API 607 | |
Products Range: | |
Size: 1/2" ~ 8" (DN15 ~ DN200) Rating: ANSI 150lb ~ 2500lb Body Materials: Forged carbon steel, Stainless steel, Duplex, Inconel, etc. Trim: A105+ENP, 13Cr, F304, F316, F51, INCONEL 625 Operation: Lever, Gear, Pneumatic operator | |
Design Feature: | Application: |
Full port or Reduce port Fire safe design Blowout-proof stem Anti-static Low emission control ISO 5211 top flange Optional locking device | Refinery Chemical Natural gas Water supply Petrochemical Power plant Pharmaceutical |
